Windows 7 Scalable 17inch 19inch Pharmacy Management System

Windows 7 Scalable 17inch 19inch Pharmacy Management System

  • Windows 7 Scalable 17inch 19inch Pharmacy Management System
  • Windows 7 Scalable 17inch 19inch Pharmacy Management System
Windows 7 Scalable 17inch 19inch Pharmacy Management System
Product Details:
Place of Origin: Guangzhou
Brand Name: ShangXu
Certification: CE certificate
Model Number: SX-QTK192 QMS
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: Standard Export Packing Cartons with Foam and other protection material
Delivery Time: 7 work days
Payment Terms: T/T, Western Union
Supply Ability: 500 set per month
Contact Now
Detailed Product Description
Name: Queue Management System Language: English/Arabic/French/Russian.etc Multiple Language Supported
Function: Queue Management,Smart Queuing Tickets Printer Material: Cold Rolled Steel
Warranty: 1 Free Year Printer: Epson 80mm Thermal Printer
Usage: QUEUE MANAGEMENT Touch Screen: IR Touch Panel
Os: Windows XP / Windows 7 Power Supply: 110-240V 50HZ/60HZ
Type: Wired / Wireless
High Light:

19inch Pharmacy Management System


17inch Pharmacy Management System


Windows 7 Scalable Management System

17''/19'' Bank Hospital Government Clinic Pharmacy Electronic Web based touch queue management system



Shangxu Queue Management System allows customers to queue for services with comfortable feeling .

>> Creates a relaxed, pleasing environment, helping to increase customer satisfaction

>> Maximises customer flow and agent efficiency

>> Fully scalable from a single to multiple sites

>> Add an unlimited number of Service/Counter

>> Agents can instantly pull from any queue/service or see all services together


Technical Specification for Queue Management System Accessories

Ticket Dispenser SX-QTK171
Cabinet All in one cold steel cabinet
LCD Display 17” SAMSUNG LCD Display with resolution of 1280*1024
Touch Screen 17” IR Touch Screen
Thermal Printer

80mm Epson Thermal Printer with auto cutter

Ticket Include (Time, Date, Ticket No., Number of Waiting Ticket, Service Name & Type, Counter Number ,your company logo and other advertising text ...).

PC Configuration

CPU: Intel 2.41Ghz

2G DDR3,500G HDD,6 USB port

Windows 7 OS installed

Speaker Inbuilt amplifier and 2 speakers
Power Supply 110V-240V



Queue Management System Software

1.Queue Management System software: control and manage the queues, can realize the function of Multiple language calling and Multiple language translation, and can realize the report statistic function

2.Interface and language and ticket format can be customized, and you can add logo or some other information on the ticket, like time, waiting people, the information can be editable

3.Arabic,English,Bengali,French,Russia,Spanish and etc multiple language can be supported


Counter Call Pad Unit SX-QKP21

Press Button 21 multiple function button
LCD Display 8 digits lcd display,5 digits showing the queue number of the called customer,3 digits display for number of customer waiting .
Power Supply 5V
Communication Wired or Wireless
Multiple function Button “Call”, “Recall”, “Transfer””Special Call””Store queue and callback” and etc.


Counter LED Display SX-CD04

Specifications for LED Counter Display:


8 Digits RED Color LED Counter Display


4 digits display ticket number & 2 digits display for counter number,with Arrow for direction to the counter number


The display format can be customized


110V-240 V Power Supply


Wired or Wireless available


Multimedia Player Box with Queue Status Display SX-MPB06

Specifications for Player Box :

* CPU: Dual Core 2.4GHZ

Memory 2G, SSD 32G

* OS: windows 7

*Inbuilt Multimedia and Queue Number Software,can split the screen to many zones,one side can play the advertising video,another side can play the queue information,at the bottom side can display the running text. by using the player box, make the queue number showing on the LCD screen

*Video output: at least can support the image with the resolution of 1024 × 768 / 75 Hz ;

*Supported video formats: MPEG-1,MPEG-2


*Image formats supported:JPG, BMP, static GIF


​Queue Management System Software


Unicode Queue Machine Software
Item Function
1. Queue Controller System Program Control the whole system
2. QueuePlatform software Custom set up the queue machine
3. Ticket Issuer Software take a queue number ticket and can customize the background picture and button picture and can design the button position and etc
4. Queue Report System Software give out enough useful reports



Windows 7 Scalable 17inch 19inch Pharmacy Management System 0
Windows 7 Scalable 17inch 19inch Pharmacy Management System 1
Windows 7 Scalable 17inch 19inch Pharmacy Management System 2

Electronic queuing is effective at a dispersing waiting crowds and creating a pleasent environment. It frees customers to shop while they wait, increasing impulse purchases and decreasing perceived wait times. And it allows you to communicate directly with customers via ticket, the LCD display, and the text messaging.


(1) Customers touch at a kiosk for their desired service and receive a ticket that specifies their unique call number, the service for which they selected, and the number of waiting person.


(2) While waiting for service, customers can relax, browse the advertising video and etc.


(3) The LCD Monitor can display promotional materials or advertising videos in addition to showing queued customers and other information.


(4) Customers are called to service when the Service counter clicks the call button on the hardware call pad or software call pad.


(5) Customers are called to the service window via LCD displays placed around the area.





















Windows 7 Scalable 17inch 19inch Pharmacy Management System 3

Windows 7 Scalable 17inch 19inch Pharmacy Management System 4

Windows 7 Scalable 17inch 19inch Pharmacy Management System 5
